How to Increase Bifacial Solar Panel Efficiency

If you’ve bought bifacial solar panels, then you’re already acquainted with how the technology is designed to gather sunlight from both sides to produce more energy. But if you want to realize the maximum potential from their technology, it’s also important to learn how to boost bifacial solar panel efficiency. With the proper configuration, environment and upkeep you can make your system more efficient, effective and cost-efficient for years to come.

Factors Affecting Bifacial Solar Panel Performance

Bifacial solar panel effectiveness is based on a few factors - installation, design and surroundings.

Here are the major factors:

• Ground reflectivity (albedo effect): White concrete, gravel or even snow reflects more sunlight onto the rear side of the panel and enhances bifacial gain.

• Tilt and elevation: Adequate height and tilt can maximize sunlight exposure on the north & south side.

• Temperature and soiling: Warmth and dust might change energy yield, affecting the back irradiance of bifacial modules.

• Shading and spacing: Don’t shade panels, even partially; it will impair their performance, particularly if you’ve packed them close together.

Once you know these factors, you can configure the installation to work better and decrease the Levelized Cost of Electricity (LCOE).

Tracking Systems vs Fixed-Tilt for Bifacial Solar Panels

The decision to employ fixed-tilt racking or tracking systems is another important factor of overall efficiency.

• Tracking systems: These adjust panel angles throughout the day, to best capture available sunlight. Bifacial gain can be enhanced by 15-20% thanks to their dual-axis trackers.

• Fixed-tilts system: Though more affordable and easier to install, they capture less sunlight during early and late hours.

For maximum energy output, particularly in the commercial setting, tracking systems are the better. It is recommended that residential fixed-tilt systems are well-designed when space and costs are constrained.

Optimizing Ground Albedo for Bifacial PV Systems

The albedo impact is an important aspect of the performance of bifacial solar panels. The high-albedo surface reflects additional sunlight onto the back side of these panels, enhancing output.

• Surfaces such as light colored gravel or sand and concrete also enhance the performance of bifacial PV.

• Other types of artificial reflection surfaces may be employed in large-scale applications to increase reflectivity.

Even a minor improvement in ground reflectivity can result in 5-10% enhancement of bifacial gain - an easy, low cost and high return optimization.

Cost-Benefit of Bifacial Solar Modules (Gain vs Cost)

At first glance, bifacial solar panels would appear to be the more costly options compared with monofacial ones. But in the long run, they tend to pay off despite an initial cost:

• In the perfect scenario, as much as 30% more energy is produced.

• Increased service life with the top technology cells such as TOPCon or Heterojunction (HJT) solar cells.

• Improved LCOE courtesy of increased generation.

Bifacial solar panels make economic sense Trina Solar and LONGi Solar are already producing effective bifacial panels for a fair return for residential or commercial owners.

Tilt Angle and Spacing Best Practices for Bifacial Modules

Good design and installation are essential to realizing the potential of bifacial.

• Don’t interrupt the angle and try to keep between 25°-35° based on site location and sunlight intensity.

• Good clearance between rows of modules should be maintained in order to keep soiling and shading effects to a minimum.

• Avoid terrains that would obstruct the ground which reflects light.

• For rooftop applications, lift panels some distance from roof tops to capture light on the back side.

Correct bifacial solar panel tilt and azimuth settings can have a large impact on system efficiency and performance over time.

Maintenance Tips for Long-Term Efficiency of Bifacial Solar Panels

• Clean and well-maintained panels are a must.

• Arrange periodic cleaning in order to avoid the accumulation of dust and fast soiling losses.

• Check the back as some dirt gets collected unnoticed.

• Look for cracks or frame misalignment following storms.

• Use a battery management system or inverter analytics to track temperature and look for anomalies.

These tasks ensure top performance, prevent abrasion and allow your system to live a longer life.

Reducing Temperature and Soiling Losses in Bifacial Solar Panels

Two silent performance killers: heat and dust. Here’s what you can do to minimize their effect:

• Maintain panel ventilation to manage heat generation and reduce the impact of bifacial temperature coefficient effect.

• Apply an anti-soiling film or regular cleaning in dusty areas.

• Clip back surrounding trees and foliage to avoid shading.

Controlling these factors will help to maintain the panels’ output and ultimately realise maximum energy generation.

Final Thoughts

Learning how to increase bifacial solar panel efficiency is the first step toward optimizing your solar investment. With the right installation angle, reflective surface, and maintenance habits, you can achieve better performance, lower costs, and long-term sustainability.

Explore Bifacial Solar Panels at Direct Solar Power to find high-quality solutions designed for maximum efficiency and durability in any environment.

Frequently Asked Questions

1. What is the expected efficiency gain of bifacial solar panels compared to monofacial ones?

Bifacial panels can generate 10-30% more energy than monofacial panels depending on installation and surface reflectivity.

2. How does ground albedo influence the performance of bifacial modules?

A high-albedo surface reflects more sunlight onto the rear side of the module, directly improving bifacial gain.

3. Do bifacial solar panels need tracking systems to perform well?

Not necessarily. While tracking systems enhance performance, well-designed fixed-tilt systems can still deliver strong results with proper spacing and tilt.

4. How much does soiling and module temperature reduce bifacial panel output?

Heavy dust or high temperatures can reduce efficiency by 5-15%. Regular cleaning and ventilation help maintain optimal output.

5. Are bifacial solar panels cost-effective for rooftop installations?

Yes. Though slightly costlier upfront, they offer higher energy yield and better long-term returns due to improved efficiency.
